A reinforcement learning system that trains a poker AI agent to play No-Limit Texas Hold'em through self-play, using the REINFORCE policy gradient algorithm.
The agent — nicknamed UGO — learns to decide when to fold, call, or bet, and how much to bet, by playing thousands of games against past versions of itself and optimizing for cumulative reward.
Table of Contents
AIs of Spades trains a poker agent using the following pipeline:
- Simulation — A pool of worker processes runs parallel poker games. Each worker plays UGO against sampled opponents from a checkpoint pool (past versions of itself).
- Learning — The main process collects all trajectories, computes the REINFORCE loss on GPU, and updates the network.
- Checkpointing — The updated model is saved periodically and added to the opponent pool, so future games are played against an increasingly diverse set of strategies.
Key features:
- Self-play with population diversity — opponents are sampled from the full history of checkpoints, not just the latest version
- Curriculum learning — showdown rewards are amplified early in training to teach card strength, then decay as strategic play becomes relevant
- Per-action baselines — separate rolling baselines for fold/call/bet reduce gradient variance without a separate value network
- Structural bonuses — reward shaping for eliminations, survival, steals, and showdowns, none of which encode direct knowledge of hand strength
Two neural network architectures are implemented, both subclassing PokerNet.
All models share the same output interface:
action_logits—[B, 3]raw logits for FOLD / CALL / BETbet_mean—[B, 1]normalized bet fraction ∈ (0, 1) via sigmoidbet_std—[B, 1]standard deviation for the bet distribution via exp+clamp
A Transformer-based model with recurrent cross-hand state. Default and recommended.
Input Encoders (each produces a d_model-dim token)
├── CardsEncoder — hole + board cards via self-attention
├── BetsNN — 64×8 action history via MLP
├── ObsNN — 10 scalar features (stacks, pot, street, ...)
├── hand_state_proj — per-hand recurrent state (reset each hand)
├── game_state_proj — cross-hand recurrent state (persists the session)
└── opp_proj × 5 — one token per opponent (randomly shuffled)
↓
TransformerTrunk
├── All tokens + learnable CLS token
├── Multi-head self-attention (4 heads, 2 layers)
└── Returns CLS hidden state
↓
Output Heads (from CLS)
├── policy_head → [3] action logits
├── bet_mean_head → [1] bet mean (sigmoid)
├── bet_std_head → [1] bet std (exp + clamp to [1e-4, 1.0])
├── hand_state_head → updated hand state
└── game_state_head → updated game state
Key hyperparameters (defaults):
| Parameter | Value | Description |
|---|---|---|
d_model |
64 | Embedding dimension throughout |
trunk_heads |
4 | Attention heads in main trunk |
trunk_layers |
2 | Transformer layers in main trunk |
cards_heads |
4 | Attention heads in card encoder |
hand_state_dim |
64 | Per-hand recurrent state size |
game_state_dim |
64 | Cross-hand recurrent state size |
shuffle_opponents |
True | Randomly permute opponent tokens |
A multi-branch CNN architecture. Lighter and simpler, but less expressive.
Branches (processed in parallel)
├── CardsCNN — convolutional encoder on [B, 1, 5, 13] card grid
├── BetsNN — MLP on flattened action history
└── StateFusionNN — MLP on hand + game state
↓
Concatenate → MLP trunk → Output heads
UGO is trained with REINFORCE with per-action baselines and entropy regularization.
Loss components:
disc_loss = mean( -advantage × log_prob(action) )
cont_loss = mean( -advantage × log_prob(bet_amount) ) # BET steps only
clamped to [-5, 5] per step
entropy_bonus = -entropy_coef × H(π) # maximize entropy
diversity_penalty = coef × Σ relu(mean_p - hi) + relu(lo - mean_p)
# fires when mean action prob
# exits [lo, hi] band
total_loss = disc_loss + continuous_weight × cont_loss
+ diversity_penalty + entropy_bonus
Advantages:
raw_advantage = reward - baseline[action_type]
advantage = (raw_advantage - mean) / (std + ε) # globally normalized
baseline[a] = rolling mean of rewards for action a
over the last action_baseline_window epochs
Gradient flow:
- Backward pass on GPU
- Gradient clipping to L2 norm ≤
grad_clip_norm - Adam optimizer with StepLR decay
Curriculum:
The showdown_reward_multiplier linearly decays from 2.0 → 1.0 over 30000 epochs, amplifying card-strength signal early in training.
games_per_epoch and hands_per_game can be scheduled as milestone dictionaries to gradually increase data complexity.
- Python 3.12 — pinned; some compiled deps don't build on 3.14+
- UV — dependency manager. Install UV
- Git
Optional:
- CUDA-capable GPU — required for the GPU SLURM script; CPU training is supported but slower
- SLURM cluster — for HPC job submission
git clone https://github.com/CogitoNTNU/AIs-of-spades.git
cd AIs-of-spades
# Base dependencies only
uv sync
# With Weights & Biases experiment tracking (recommended for training)
uv sync --group train
# All groups (base + training + dev + docs)
uv sync --all-groupsFor development, install pre-commit hooks:
uv run pre-commit installStart a new training run:
uv run python src/main.py --run-name my-runResume from the latest checkpoint:
uv run python src/main.py --run-name my-run --resume-latestResume from a specific checkpoint:
uv run python src/main.py --resume-from res/checkpoints/my-run/SimoNet/epoch_1000.pt| Argument | Type | Default | Description |
|---|---|---|---|
--run-name |
str | None | Sets wandb run name and checkpoint dir to res/checkpoints/<name> |
--resume-latest |
flag | False | Resume from the latest checkpoint in the checkpoint directory |
--resume-from |
str | None | Path to a specific checkpoint file |
--num-workers |
int | None | Override num_workers from config (set automatically by SLURM) |
--config-file |
str | config.yaml |
Path to config file, relative to src/ |
If both --resume-latest and --resume-from are set, --resume-from takes priority.
To play against a trained model in the browser:
uv run python src/start_ui_host.pySee src/README.md for UI configuration details.
All hyperparameters are in src/config.yaml.
weight_manager:
model_class: "SimoNet" # "SimoNet" or "EvenNet"
max_models: 100 # Max checkpoints to keep on disk
keep_latest: 20 # Always retain the N most recent checkpoints
sampling_mode: "linear" # Opponent sampling: "uniform", "linear", or "exponential"
checkpoint_dir: "res/..." # Overridden by --run-name at runtime
learning_loop:
learning_rate: 3e-4
lr_decay_steps: 100
lr_decay_gamma: 0.97
epochs: 100000
save_interval: 100
num_workers: 8 # Parallel game workers (overridden by --num-workers)
grad_clip_norm: 1.0
continuous_weight: 0.01 # Weight of bet-size loss relative to action loss
entropy_coef: 0.05 # Policy entropy regularization
diversity_coef: 0.15 # Anti-collapse penalty coefficient
diversity_lo: 0.08 # Lower bound of acceptable action probability
diversity_hi: 0.80 # Upper bound of acceptable action probability
action_baseline_window: 50 # Rolling window for per-action baselines
# Both fields support milestone scheduling: { epoch: value, ... }
games_per_epoch:
0: 5
500: 10
1000: 20
5000: 30
10000: 50
hands_per_game:
0: 70
300: 50
1000: 40
5000: 30
10000: 25
game_loop:
hand_reward_decay: 0.8 # Discount (γ) across hands within a game
stack_lo: 50.0 # Min starting stack (in big blinds)
stack_hi: 200.0 # Max starting stack
# Structural bonuses — all zero-knowledge (no card-strength info encoded)
elimination_bonus: 40.0 # Per opponent eliminated
survival_bonus: 200.0 # When UGO is last player standing
isolation_bonus: 5.0 # For playing heads-up
showdown_bonus: 2.0 # For reaching showdown
steal_bonus: 8.0 # For winning an uncontested pot
# Curriculum: showdown reward multiplier decays start → end over N epochs
showdown_reward_multiplier_start: 2.0
showdown_reward_multiplier_end: 1.0
showdown_reward_multiplier_epochs: 30000Opponent sampling modes:
| Mode | Behavior |
|---|---|
uniform |
Equal probability for all checkpoints |
linear |
Weight ∝ epoch number (bias toward recent) |
exponential |
Weight ∝ 2^epoch (strong recency bias) |
Two scripts are provided for NTNU's Idun/EPIC cluster.
Time limit: 4 hours
Partition: GPUQ
GPUs: 1
CPUs: 14 (12 workers + 2 for main process)
Memory: 32 GB
Time limit: 100 hours
Partition: default (CPU nodes)
CPUs: 6 (4 workers + 2 for main process)
Memory: 50 GB
Both scripts read the JOB_NAME environment variable to set the job name, output directory, and checkpoint path simultaneously:
JOB_NAME="ugo-v2" sbatch trainingCPUs.slurm
JOB_NAME="ugo-v2" sbatch training.slurmThis will:
- Write logs to
slurm_outputs/ugo-v2/output.txtandoutput.err - Save checkpoints to
res/checkpoints/ugo-v2/ - Name the wandb run
ugo-v2 - Rename the SLURM job to
ugo-v2viascontrol update
Without JOB_NAME, the default name ais-of-spades is used.
The scripts automatically resume from the latest checkpoint (--resume-latest) and set --num-workers based on the allocated CPUs minus 2.
AIs-of-spades/
├── src/
│ ├── main.py # Entry point
│ ├── config.yaml # All hyperparameters
│ ├── nn/
│ │ ├── poker_net.py # Abstract base class for all models
│ │ ├── simo_net/ # SimoNet (Transformer-based, default)
│ │ └── even_net/ # EvenNet (CNN-based, alternative)
│ ├── training/
│ │ ├── learning_loop.py # Training loop, loss, optimizer
│ │ ├── game_loop.py # Game simulation, reward shaping
│ │ ├── weight_manager.py # Checkpoint pool & opponent sampling
│ │ ├── player_agent.py # Agent wrapper
│ │ └── wandb_compat.py # Weights & Biases integration
│ ├── pokerenv/ # No-Limit Texas Hold'em environment
│ │ ├── table.py # Main Gym environment
│ │ ├── player.py # Player class
│ │ ├── observation.py # Observation data structures
│ │ ├── common.py # PlayerAction, PlayerState enums
│ │ └── table_engine/ # Betting, pot, and street logic
│ └── ui/ # Browser-based interactive UI
├── training.slurm # SLURM script — GPU
├── trainingCPUs.slurm # SLURM script — CPU only
├── tests/ # Test suite
└── docs/ # Documentation source
uv run pytest --doctest-modules --cov=src --cov-report=htmluv run mkdocs build
uv run mkdocs serve # Preview at http://127.0.0.1:8000/This project is developed by Cogito NTNU.
 Simone Elia |
 Federico Hrvatin |
 Even Ytterli Tokle |
 Miheer Gautam |
 Daniel Meling |
Distributed under the MIT License. See LICENSE for more information.
